Vancouver heat-pump ductwork pricing under the BC Energy Step Code
Heat-pump ductwork in Vancouver is priced by linear foot, register and ton, with Step Code sealing and ventilation work quoted as separate lines.
What to take away
- Vancouver ductwork is priced in three units: linear foot of run, register served, and ton of capacity. Ask for all three.
- Step Code work adds two lines national guides skipenvelope-driven ventilation ducting and commissioning documentation.
- A 2,400 sq ft heat-pump retrofit with new ductwork and a balanced HRV typically runs $28,000 to $46,000 for that scope. Equipment sits on top.
- City of Vancouver mechanical permits typically run $300 to $1,200 on a residential job.
- Vancouver quotes carry a premium over Calgary and Toronto, from labour, seismic bracing, permits and documentation.
The three units behind a Vancouver ductwork quote
Three units carry almost every quote here. Linear foot prices trunk and branch runs. Per register prices boots, grilles, drops and balancing dampers. Per ton ties the air-moving side to capacity.
Three units in every duct quote
Linear foot
- Covers
- Trunk and branch runs
- Includes
- Duct, sealant, insulation
- Rises with
- Ceiling height, access
- Risk if wrong
- Undefendable lump sum
Per register
- Covers
- Boot, grille, damper
- Includes
- Branch takeoff, balancing
- Rises with
- Register count
- Risk if wrong
- Leaks at each assembly
Per ton
- Covers
- Air-moving vs capacity
- Includes
- Static pressure target
- Rises with
- Undersized ducts
- Risk if wrong
- Unpaid callbacks
The per-foot rate covers material and labour for a sealed, insulated run: duct, sealant, insulation, hangers, and installation hours. Ceiling height, access and finished walls push it up.
Per-register pricing covers the boot, diffuser, balancing damper and branch takeoff. Fourteen registers means fourteen places air can leak.
Per-ton pricing ties duct size to the heat pump. Undersized ducts raise static pressure, cut airflow, and make the compressor run longer. That returns as a callback, and callbacks are unpaid.
A quote template with real numbers keeps those three units as separate lines, which makes the total defensible when a homeowner asks why.
What the BC Energy Step Code adds
Vancouver applies the Step Code with local stringency. A tight envelope cuts natural leakage, so fresh air has to be supplied on purpose. That work lands on HRV or ERV ducting, a separate system with its own runs, balancing and price.
Compliance also requires documentation. Blower door results and ventilation commissioning feed the energy model, and someone has to produce that file.
Sealing and insulation are inspected, not assumed. NFPA 90A sets insulation and installation requirements for ventilating systems, and those details drive labour hours.
Duct size follows a room-by-room load calculation. NRCan electric heat pump guidance supports units and ductwork sized for both heating and cooling airflow.
Illustrative per-unit prices for a Vancouver retrofit
The figures below are illustrative. Substitute your own labour and material numbers.
Illustrative per-unit prices
| Line | Unit | Illustrative figure | Covers |
|---|---|---|---|
| Supply and return trunk | per linear foot | $45 to $85 | Sealed, insulated run, hangers, labour |
| Branch run to register | per register | $180 to $320 | Boot, damper, diffuser, takeoff |
| Ductwork per ton | per ton | $900 to $1,600 | Trunk sizing, return path, static target |
| HRV or ERV ducting | per point | $250 to $450 | Bathroom, kitchen, laundry, living runs |
| Seismic bracing and flex connectors | per connection | $120 to $260 | Hardware and labour at crossings |
| Commissioning and documentation | per job | $600 to $1,400 | Balancing, airflow readings, Step Code file |
| City mechanical permit | per job | $300 to $1,200 typical | Scales with scope and declared value |
Illustrative Vancouver retrofit line prices
- $45 to $85per linear foot, supply and return trunk
- $180 to $320per register, branch run
- $900 to $1,600per ton of capacity
- $250 to $450per HRV or ERV point
A 2,400 sq ft Vancouver house with a new trunk, fourteen registers, a four-ton system and a balanced HRV typically prices near $28,000 to $46,000 for ductwork and ventilation, with equipment added.
Where Vancouver sits against Toronto and Calgary
Where Vancouver sits
- Labour.Vancouver sheet metal and refrigeration billing rates typically run 10 to 20 percent above Calgary and 5 to 15 percent above Toronto in bids we see. Treat those as typical ranges, not published indices.
- Seismic bracing.BC quotes carry bracing and flexible connections at equipment and crossings, usually $120 to $260 per connection. Ontario and Alberta quotes often leave the line out.
- Permits and documentation.The City mechanical permit and the Step Code file both add money.
On a comparable fourteen-register house, the same scope typically runs $3,000 to $7,000 more in Vancouver than Calgary, and $2,000 to $5,000 more than Toronto. Toronto ductwork pricing for older homes and condo towers shows how much of a quote comes from the building rather than the city.
Permits, labour burden and rebate amounts
Vancouver requires mechanical permits for heat pump and ventilation work, with inspections scheduled before the drywall closes. Residential mechanical permits typically run $300 to $1,200 depending on declared value and scope. Confirm against the City's current fee schedule before quoting.
Labour burden is the number contractors forget. WorkSafeBC coverage, EI, CPP, vacation pay and non-billable travel sit on top of the wage rate. US wage data for HVAC mechanics and installers shows how much of a bid is labour rather than parts.
Rebate amounts move. BC Hydro home heat pump rebates have been advertised between roughly $2,000 and $8,000 depending on income qualification, equipment tier and program year. Treat that as indicative and verify current terms with the utility.
NRCan and provincial rebate programs set out which measures qualify, and ductwork rarely appears on the list. Price it at full value and show the rebate as a credit.
Example: 2,400 sq ft Vancouver house, heat pump retrofit
Scope: cold-climate heat pump, new supply and return trunk, balanced HRV.
- Measure and model. Room-by-room load calculation and envelope review set duct sizes and equipment capacity before anyone prices the job.
- Design the layout. Supply and return runs, HRV routing and zoning drawn to fit existing cavities, with bracing and access panels marked.
- Price the work. Labour, materials, permits and commissioning listed separately, with the rebate estimate shown as a credit rather than a discount.
- Install and seal. Ducts sealed, insulated and pressure tested, HRV balanced, airflow recorded at each register.
- Commission and document. Blower door and ventilation results go into the Step Code file, and the homeowner gets paperwork for the rebate application.
